Electric diaphragm pump VICENTINI mod. CICLOPE 2000

Electric diaphragm pump VICENTINI mod. CICLOPE 2000

Location:Isola Vicentina, Italy

Description

The electric diaphragm pump VICENTINI mod. CICLOPE 2000 is a classic high-performing industrial pump. Originally manufactured in 1959, this model combines vintage durability with modernized internal components, making it a standout solution for high-pressure fluid handling tasks.



With a nominal delivery capacity of 2000 liters per hour and a maximum working pressure of 15 bar, this pump is equipped to handle demanding applications. Its single-piston design, powered by a 3 kW motor, ensures steady, controlled flow and efficient energy use. The pump runs on a three-phase power supply of 400 Volts / 50 Hz, making it compatible with industrial power standards.



The refurbishment includes a new diaphragm, new balls and seats, a new piston basket, new oil, and new belts, ensuring that the pump operates as if it were new. However, please note that the pump is provided without a lung damper.



Weighing approximately 500 kg and with overall dimensions of 1050 mm (width) x 450 mm (length) x 1055 mm (height), the pump offers a robust and space-efficient design, making it an ideal choice for various industrial environments that require a high-capacity, reliable diaphragm pump.

Specifications

ManufacturerVICENTINI
Modelmod. CICLOPE 2000
Year1959
ConditionRefurbished
Stock Number7026
Pump nominal delivery lt/h2000
Max. working pressure bar15
N° of pistons1
Power kW3
Tension Volt / Frequency Hz400/50
Phasethree phase
Weight Kg500
Electric diaphragm pump overall dimensions (width) x (lenght) x (height) mm1050 x 450 x 1055
Attention!!!diaphgram pump supplied with new diaphragm, new balls, new balls seats, new piston basket, new oil and new belts but without lung dumper
