HEAT TREATMENT FURNACE - KILN
Sold
HEAT TREATMENT FURNACE - KILN
Location:Isola Vicentina, Italy
Description
Art. 4300 N ° 01 Heat treatment furnace - kiln
- Second hand machine
- Manufacturing year 2009
- Useful for tempering, annealing, normalizing and other
thermal treatments in general
- Useful loading capacity 58 CM
- Useful loading dimensions 6500 x 3000 x h 3000 mm
- Max temperature 1000 ° C
- Max loading weight 40 Ton / cycle
- NEW Insulation lining in ceramic fiber with wall thickness 250 mm
(suitable up to a nominal temperature of 1260 ° C) refractory and cup
locks
- N ° 08 Burners
- Burner feeding: LPG (Liquid Propane Gas) (in case of need, with a
small extra cost, could be changed to Natural Gas (CH4)
- Thermal power installed 2.000.000 Kcal / h approx
- Electrical power installed 20 Kw approx
- Electric switchboard with NEW cycles programming and control
instruments
- N ° 01 Car on rails with motor for automatic extraction
- Car overall dimensions 6800 x 3825 x h 800 mm
- Guillotine door in 02 halves to limit the overall dimension in height
- External overall dimensions (when installed): 6300 x 5200 x h 6000
mm approx
- Necessary space to install and operate the kiln: 8 x 10 mts approx
- Complete with manual, electrical drawings and CE certificate
Please notice !! The kiln has been dismantled and transported by us, with care, and is now stocked inside a covered deposit.
Specifications
Condition | Used |
Stock Number | 3032 |
