Muffled gas turbo kiln SAFF - Usable also as not muffled turbo kiln
Sold
Muffled gas turbo kiln SAFF - Usable also as not muffled turbo kiln
Location:Isola Vicentina, Italy
Description
Art. 4345 N ° 01 Muffled gas turbo kiln SAFF - Usable also as not muffled turbo kiln
- Second hand machine
- Max firing temperature: 1100 ° C
- Useful loading capacity: 1 cbm
- Intenal insulation: ceramic fiber and thin refractory slabs + muffle done with thin refractory slabs
- N ° of cars: 02 (N ° 01 inside + N ° 01 in stand-by)
- Useful loading dimensions: 900 x 1300 x h 950 mm
- N ° of burners: 10 inside muffle + 2 outside the muffle (can be
excluded from the electric switchboard)
- Burners feeding: Natural gas (CH4)
- Combustion fans: Kw 0,75 for the burners inside the muffle + Kw 0,37
for the burners outside the burners
- N ° 02 Completely Independent controlled zones (gas valve + air valve
and combustion fan are independents - one zone controls the burners
inside the muffle and the other the burners outside the muffle)
- Complete with electric switchboard with computer ABLY TC 85
- Automatic chimney opening controlled by the microprocessor
(probably, to be verified, with real time controlof the pressure inside
the firing chamber)
- Stainless steel heat exchanger for the dryer complete with fan 0,75 Kw
Specifications
Condition | Used |
Stock Number | 4333 |
